Backend Overview

Proxbox uses a separate FastAPI service as its backend. The NetBox plugin does not talk to Proxmox directly.

How It Works

The backend:

  • connects to Proxmox
  • connects back to NetBox
  • exposes HTTP endpoints used by the plugin
  • supports SSE streaming (text/event-stream) for real-time per-object sync progress
  • can optionally provide WebSocket updates for sync progress

The NetBox plugin stores and manages endpoint records, then triggers sync requests against the backend. Current user-facing sync flows are job-driven and primarily consume backend SSE endpoints. Legacy WebSocket/browser integrations still exist for compatibility, but background jobs plus SSE are the main path in current code.

Sync Endpoints

Current plugin sync endpoints enqueue NetBox background jobs (ProxboxSyncJob). The job worker then consumes the backend SSE stream (.../stream) to completion.

Plugin Path Backend Path Used By Job Description
sync/devices/ GET /dcim/devices/create/stream Queue device sync
sync/storage/ GET /virtualization/virtual-machines/storage/create/stream Queue storage sync
sync/virtual-machines/ GET /virtualization/virtual-machines/create/stream Queue VM sync
sync/virtual-machines/virtual-disks/ GET /virtualization/virtual-machines/virtual-disks/create/stream Queue virtual disk sync
sync/virtual-machines/backups/ GET /virtualization/virtual-machines/backups/all/create/stream Queue VM backup sync
sync/virtual-machines/snapshots/ GET /virtualization/virtual-machines/snapshots/all/create/stream Queue VM snapshot sync
sync/full-update/ GET /full-update/stream Queue full multi-stage update

How Sync Streaming Works In Current Code

  1. The user clicks a sync button in the NetBox UI.
  2. The plugin enqueues a ProxboxSyncJob in NetBox's default RQ queue.
  3. A NetBox RQ worker executes that job and opens the backend SSE endpoint.
  4. As the backend emits SSE events, the job logs progress and stores structured result payloads on the Job row.
  5. The user follows status/log/output from the NetBox background job pages.

Architecture

Proxbox Architecture Image
